Brother MFC-J2330DW Service Manual

Confidential
2-10
3 ERROR INDICATION
To help the user or the service personnel promptly locate the cause of a problem (if
any), the machine incorporates the self-diagnostic functions which display error
messages for equipment errors.
3.1 Error Code
Error
Code
Contents
Refer to
page:
0D00 Paper jam during duplex-printing
The recording papers are fed in reverse on the platen when switchback
drive is started, triggering switchback sensor as paper feeding condition.
2-24
0E00 Defective during duplex-printing
Switchback sensor detects paper feed condition at out of specified timing
during switchback.
2-24
1300 Defective during duplex-printing
Registration sensor detects paper feed condition at out of specified timing
during switchback.
2-25
1500 Paper jam during duplex ejecting
Recording paper is not able to be ejected since it is longer than 840 mm
when ejecting the paper. (The registration sensor stays in the paper
feeding condition during ejecting.)
2-25
1700 Recording paper size error (duplex-printing/duplex-copying)
- Paper width is narrower than 95.5 mm (detection by paper width
sensor)
- Paper length is longer than 245.9 mm (detection by registration sensor)
- Paper length is shorter than 143.5 mm (detection by registration sensor)
2-26
1800 Paper jam during duplex-printing
Registration sensor does not detect paper feed within specified pulse
numbers in the second side paper re-feed.
2-26
2000 Cannot identify a black ink cartridge.
The ink cartridge detection sensor and the ink remaining sensor are
detecting.
2-27
2001 Cannot identify a yellow ink cartridge.
The ink cartridge detection sensor and the ink remaining sensor are
detecting.
2-27
2002 Cannot identify a cyan ink cartridge.
The ink cartridge detection sensor and the ink remaining sensor are
detecting.
2-27
2003 Cannot identify a magenta ink cartridge.
The ink cartridge detection sensor and the ink remaining sensor are
detecting.
2-27
2100 Black ink cartridge side IC chip relation defective
- Detecting setting wrong color
2-27
2101 Yellow ink cartridge side IC chip relation defective
- Detecting setting wrong color
2-27
2102 Cyan ink cartridge side IC chip relation defective
- Detecting setting wrong color
2-27
2103 Magenta ink cartridge side IC chip relation defective
- Detecting setting wrong color
2-27
