Brother MFC-J2330DW Service Manual

5-50
Confidential
1
Model code, Serial number, Country code,
Checksum of WSW, PSW, USW, and FSW
*1
28
Printed page count per tray: Paper tray #1, Paper
tray #2, Label
*2
, Manual feed slot, MP tray, Paper
tray #3
*2
2
Version of main firmware, Production date &
time, Checksum,
ROM1 checksum
*1
29
Printed page count of the present cartridge, Printed
page count of the previous cartridge
3
Version of boot firmware
*1
, Real-time clock
(RTC) check result
*1
, RTC backup check
result
*1
(OK: Backup completed, NG: Backup
failed)
30
Average coverage of all cartridges
31
Average coverage of the present cartridge,
Average coverage of the previous cartridge
4
Head property information/Head voltage
correction value/Head calibration data –
calibration ratio – Presence of variation
calibration data (1:Exist, 0: Not exist)
32
Recording paper jam count: Total count, when
printing the second side in duplex printing
33
Recording paper jam count per tray: Paper tray #1,
Paper tray #2, Label
*2
, Manual feed slot, MP tray,
Paper tray #3
*2
5 First side CIS type/Second side CIS type
6
Total ink drop count from a new head (including
flushing)
7 Ink drop count after replacement of ink cartridge
34
Paper pull-in failure count
: Paper tray #1, Paper
tray #2, Label
*2
, Manual feed slot, MP tray, Paper
tray #3
*2
8 Ink drop count after detection of "Ink Low"
9
Ink drop count for droplets jetted out onto the
platen
*1
35
Roller cleaning count:
Paper tray #1, Paper tray
#2, MP tray, Paper tray #3
*2
10 Ink drop count by cleaning from ink renewal
11
Ink cartridge change count (High-yield and super
high-yield ink cartridges)
36 Paper piece removal count, Job cancel count
37 ADF jam count: Simplex, Duplex
12
Ink cartridge detection failure count (Cannot
Detect display count), "Ink Low" count
38
Scanning count: ADF, ADF duplex, FB, FAX,
Scanner
39
Home positioning error code of the CIS unit/
Home positioning detection log data
*1
13
Ink drop count at the previous replacement of ink
cartridge
40
Purge count: Purge, Sensor purge, Wipe, Black
flushing, Color flushing, Flushing count error
detection count
14
Ink drop count after detection of "Ink Low" at the
previous replacement of ink cartridge
15
Ink drop count by cleaning at the previous
replacement of ink cartridge
41 Purge count (black)
*3
42 Purge count (color)
*3
16 Ink drop count at ink remaining failure 43 Purge count (Other)
*3
17
Total printed page count, A3 paper printed page
count
44 Initial purge log
*1
(FF: normal end)
45 Initial purge execution time
*1
18 Printed page count: PC print, Copy, FAX 46 Last three purge logs
19 Printed page count:
Media, List, Web Connect
47
Total power-ON time, Power-ON count,
Capacitor
failure detection count
20
Printed page count: AirPrint、iPrint、Google
Cloud Print
48
Machine error history(Error code: Date of
occurrence: Machine temperature degree-C at
the time of occurrence)
21
Printed page count: Test pattern,
User line
alignment, User feeding amount adjustment, Other
49
Communications error history (Error code: Date
of occurrence)
22 Total printed page count in duplex printing
23
Printed page count in duplex printing: PC print,
Copy, Other
50 Machine information backup file version
*1
51 Sensor status
*4
