Ref Description P/N Notes
1 Mode Switch 766282
2 Key Switch (OFF – ON – START) 768746
3 Concealed Side Mount Remote Control 766553
4 *Remote Control Harness – Included with Remote Control
5 Mode Switch Connection –
6 Key Switch Connection –
7 Trim Switch Connection –
8 Remote Control to NMEA 2000 Network Connection –
9 Accessory Power Out (12 VDC) –
10 Remote Control Network Connection –
11 Network Power In (12 VDC) –
12 Oil Level 1 & 2 –
13 Fuel Level 1 & 2 –
14 Connector - Accessory Foot Throttle –
15 Foot Throttle Kit, Bulkhead Mount 767747 Optional Accessory
16 *Foot Throttle Harness 587167
15 Foot Throttle Kit, Floor Mount 766567 Optional Accessory
16 *Foot Throttle Harness 587167
17 Terminator Kit 764155
18 Power Node and Tee Kit 767433 3 Amp fuse
19 Connection to NMEA 2000 Digital Display –
20 Connection to NMEA 2000 Network –
21 NMEA 2000 Buss Cables –
2 ft. (0.6 m) 765132
6 ft. (1.8 m) 764161
15 ft. (4.5 m) 764162
25 ft. (7.6 m) 764163
22 Backbone Buss Cables –
15 ft. (4.5 m) 587173
20 ft. (6.0 m) 587174
25 ft. (7.6m) 587175
NS Backbone Buss Cable Extensions –
1 ft. (0.3 m) 587176
2 ft. (0.6 m) 587177
4 ft. (1.5 m) 587178
10 ft. (3.0 m) 587179
15 ft. (4.5 m) 587180
20 ft. (6.0 m) 587181
25 ft. (7.6 m) 587182
23 Network Power Cable, 15 ft. (4.5 m) 587184 10 Amp fuse
23 Network Power Cable, 25 ft. (7.6 m) 587183 10 Amp fuse
NS Network Power Cable Extension, 5 ft. (1.5 m) 587185
NS Network Power Cable Extension, 10 ft. (3.0 m) 587186
24 Fuel Tank Sender –
25 Battery Cable, 10 ft. (3.0 m) 587205
25 Battery Cable, 15 ft. (4.5 m) 587301
25 Battery Cable, 20 ft. (6.0 m) 587302
26 Connection to NMEA 2000 Accessories – GPS, Triducer, etc.
* "Y" Harness (Optional accessory) 587230
Use to power digital displays & accessories to be
powered when the key switch is ON.
