Diagrams
Mechanical Remote Controls
Mechanical Remote Controls
08 Mechanical Remote Controls with UCM,
Using a NMEA 2000 Digital Display
Ref Description P/N Notes
1 Universal Control Module (UCM) 5008963 Converts Mechanical to Digital Shift & Throttle
2 Network Power In (12 VDC) –
3 Remote Control Network Connection (to engine) –
4 NMEA 2000 Network Connection –
5 SystemCheck Connection (Not Used) –
6 Key Switch Switch Connection –
7 Trim Switch Connection –
9 Ignition, Trim & Tilt Harness –
15 ft. (4.5 m) 763543
20 ft. (6.0 m) 763544
25 ft. (7.6 m) 763545
28 ft. (8.5 m) 763546
10 Mechanical Remote Control – Refer to Parts & Accessories Catalog
11 Trim Switch Connection –
12 Key Switch Switch Connection –
13 NMEA 2000 Network Power Supply Kit 764157
14 Terminator Kit 764155
15 Connection to NMEA 2000 Digital Display –
16 Connection to NMEA 2000 Network –
17 Control Cables (Shift & Throttle) –
18 NMEA 2000 Buss Cables –
2 ft. (0.6 m) 765132
6 ft. (1.8 m) 764161
15 ft. (4.5 m) 764162
25 ft. (7.6 m) 764163
19 Network Power Cable, 15 ft. (4.5 m) 587184 10 Amp fuse
19 Network Power Cable, 25 ft. (7.6 m) 587183 10 Amp fuse
NS Network Power Cable Extension, 5 ft. (1.5 m) 587185
NS Network Power Cable Extension, 10 ft. (3.0 m) 587186
20 Backbone Buss Cables –
15 ft. (4.5 m) 587173
20 ft. (6.0 m) 587174
25 ft. (7.6m) 587175
NS Backbone Buss Cable Extensions –
1 ft. (0.3 m) 587176
2 ft. (0.6 m) 587177
4 ft. (1.5 m) 587178
10 ft. (3.0 m) 587179
15 ft. (4.5 m) 587180
20 ft. (6.0 m) 587181
25 ft. (7.6 m) 587182
21 Connection to NMEA 2000 Accessories – GPS, Triducer, etc.
22 Battery Cable, 10 ft. (3.0 m) 587205
22 Battery Cable, 15 ft. (4.5 m) 587301
22 Battery Cable, 20 ft. (6.0 m) 587302
