Ref Description P/N Notes
1 MWS Harness –
12 ft. (3.6 m) 176339
15 ft. (4.5 m) 176340
20 ft. (6.0 m) 176341
28 ft. (8.5 m) 176342
2 SystemCheck Tachometer Connection –
3 Non–SystemCheck Tachometer Connection –
use purple and black to supply 12VDC to NMEA
2000 network
4 Trim Gauge Connection –
5 Warning Horn Connection –
6 Mechanical Remote Control –
7 Trim Switch Connection –
8 Key Switch Switch Connection –
9
SystemCheck Connection (Not Used) –
10 Key Switch Switch Connection –
11 Trim Switch Connection –
13 Control Cables (Shift & Throttle) –
14 Universal Control Module (UCM) 5008963 Converts Mechanical to Digital Shift & Throttle
15 Terminator Kit 764155
16 NMEA 2000 Network Power Supply Kit 764157
17 Network Power Cable, 15 ft. (4.5 m) 587184 10 Amp fuse
17 Network Power Cable, 25 ft. (7.6 m) 587183 10 Amp fuse
NS Network Power Cable Extension, 5 ft. (1.5 m) 587185
NS Network Power Cable Extension, 10 ft. (3.0 m) 587186
18 Backbone Buss Cables –
15 ft. (4.5 m) 587173
20 ft. (6.0 m) 587174
25 ft. (7.6m) 587175
NS Backbone Buss Cable Extensions –
1 ft. (0.3 m) 587176
2 ft. (0.6 m) 587177
4 ft. (1.5 m) 587178
10 ft. (3.0 m) 587179
15 ft. (4.5 m) 587180
20 ft. (6.0 m) 587181
25 ft. (7.6 m) 587182
19 Battery Cable, 10 ft. (3.0 m) 587205
19 Battery Cable, 15 ft. (4.5 m) 587301
19 Battery Cable, 20 ft. (6.0 m) 587302
