136
Diagrams
Digital Displays
12 I-Command Digital Display
Ref Description P/N Notes
1 I-Command Digital Displays and Gauges Refer to Parts & Accessories Catalog
2 START – STOP Switch 5010021
3 Key Switch/ STOP Switch 5010020
4 Dual Binacle Mount Remote Control 766564
5 *Remote Control Harness Included with Remote Control
6 NMEA 2000 Network Power Supply Kit 764157
7 Terminator Kit 764155
8 NMEA 2000 Network Connection
9 NMEA 2000 Buss Cables
2 ft. (0.6 m) 765132
6 ft. (1.8 m) 764161
15 ft. (4.5 m) 764162
25 ft. (7.6 m) 764163
10 Connection to NMEA 2000 Accessories GPS, Triducer, etc.
11 Backbone Buss Cables
15 ft. (4.5 m) 587173
20 ft. (6.0 m) 587174
25 ft. (7.6m) 587175
NS Backbone Buss Cable Extensions
1 ft. (0.3 m) 587176
2 ft. (0.6 m) 587177
4 ft. (1.5 m) 587178
10 ft. (3.0 m) 587179
15 ft. (4.5 m) 587180
20 ft. (6.0 m) 587181
25 ft. (7.6 m) 587182
12 Network Power Cable, 15 ft. (4.5 m) 587184 10 Amp fuse
12 Network Power Cable, 25 ft. (7.6 m) 587183 10 Amp fuse
NS Network Power Cable Extension, 5 ft. (1.5 m) 587185
NS Network Power Cable Extension, 10 ft. (3.0 m) 587186
13 Fuel Tank Sender
14 6–Port Hub 587172
15 Battery Cable, 10 ft. (3.0 m) 587205
15 Battery Cable, 15 ft. (4.5 m) 587301
15 Battery Cable, 20 ft. (6.0 m) 587302
