Application:
2 Stations
2 Evinrude E-TEC G2 outboards
1 DPS, 1 non-DPS
1 standard rotation, 1 counter-rotation
Mechanical Tie Bar
Ref Description P/N Notes
1 Helm, Upper Station (with Vented Fill Plug) –
2 Steering Hose, Starboard – Upper Helm to Tee Fitting
3 Steering Hose, Port – Upper Helm to Tee Fitting
4 Tee-Fitting –
5 Steering Hose, Starboard – Lower Helm to Tee Fitting
6 Steering Hose, Port – Lower Helm to Tee Fitting
7 Helm, Lower Station (with Non-Vented Fill Plug) –
8 Compensating Line – Upper to Lower Helm
9 Steering Hose, Starboard – Helm Tee Fitting to Outboard
10 Steering Hose, Port – Helm Tee Fitting to Outboard
11 Hose Connection to Outboard – Starboard
12 Hose Connection to Outboard – Port
13 By-Pass Hose – non-DPS outboard
14 Tie Bar Kits –
Two Outboard, 24 to 29 inch spacing 766568
Two Outboard, 29 to 36 inch spacing 766569
