BRP Evinrude E-TEC G2 150 HP User Manual

130
Diagrams
Mechanical Remote Controls
09 Mechanical Remote Controls with UCM,
Using an Analog Gauge Display
Ref Description P/N Notes
1 Universal Control Module (UCM) 5008963 Converts Mechanical to Digital Shift & Throttle
2 Network Power In (12 VDC) –
3 Remote Control Network Connection (to engine) –
4 Terminator Kit 764155
5 NMEA 2000 Network Connection –
6 SystemCheck Connection (Not Used) –
7 Key Switch Switch Connection –
8 Trim Switch Connection –
10 MWS Harness –
12 ft. (3.6 m) 176339
15 ft. (4.5 m) 176340
20 ft. (6.0 m) 176341
28 ft. (8.5 m) 176342
11 NMEA 2000 Network Power Supply Kit 764157
12 SystemCheck Tachometer Connection –
use purple and black to supply 12VDC to NMEA
2000 network
13 Non–SystemCheck Tachometer Connection –
14 Trim Gauge Connection –
15 Warning Horn Connection –
16 Mechanical Remote Control – Refer to Parts & Accessories Catalog
17 Trim Switch Connection –
18 Key Switch Switch Connection –
19 Control Cables (Shift & Throttle) –
20 Network Power Cable, 15 ft. (4.5 m) 587184 10 Amp fuse
20 Network Power Cable, 25 ft. (7.6 m) 587183 10 Amp fuse
NS Network Power Cable Extension, 5 ft. (1.5 m) 587185
NS Network Power Cable Extension, 10 ft. (3.0 m) 587186
21 Backbone Buss Cables –
15 ft. (4.5 m) 587173
20 ft. (6.0 m) 587174
25 ft. (7.6m) 587175
NS Backbone Buss Cable Extensions –
1 ft. (0.3 m) 587176
2 ft. (0.6 m) 587177
4 ft. (1.5 m) 587178
10 ft. (3.0 m) 587179
15 ft. (4.5 m) 587180
20 ft. (6.0 m) 587181
25 ft. (7.6 m) 587182
22 NMEA 2000 Buss Cables –
2 ft. (0.6 m) 765132
6 ft. (1.8 m) 764161
15 ft. (4.5 m) 764162
25 ft. (7.6 m) 764163
23 Battery Cable, 10 ft. (3.0 m) 587205
23 Battery Cable, 15 ft. (4.5 m) 587301
23 Battery Cable, 20 ft. (6.0 m) 587302
