BRP Evinrude E-TEC G2 150 HP User Manual

124
Diagrams
Digital Remote Controls
06 Dual Binnacle Mount Remote Control 3 & 4 Outboard
Ref Description P/N Notes
1 Trim Switch Module, 3 Engine 766583
1 Trim Switch Module, 4 Engine 766584
2 START – STOP Switch Panel, 3 Engine 766559
2 START – STOP Switch Panel, 4 Engine 766561
3 Key Switch Kit 768747
4 Dual Binacle Mount Remote Control 766564
5 *Remote Control Harness – Included with Remote Control
6 Trim Module Conneciton –
7 START – STOP Switch Connection –
8 Key Switch Switch Connection –
9 Remote Control to NMEA 2000 Network Connection –
10 Accessory Power Out (12 VDC) –
11 Remote Control Network Connection –
12 Network Power In (12 VDC) –
13 Oil Level 1 & 2 –
14 Fuel Level 1 & 2 –
15 Trim Switch Connection –
16 Terminator Kit 764155
17 Power Node and Tee Kit 767433 3 Amp fuse
18 Connection to NMEA 2000 Digital Display –
19 Connection to NMEA 2000 Network –
20 NMEA 2000 Buss Cables –
2 ft. (0.6 m) 765132
6 ft. (1.8 m) 764161
15 ft. (4.5 m) 764162
25 ft. (7.6 m) 764163
21 Backbone Buss Cables –
15 ft. (4.5 m) 587173
20 ft. (6.0 m) 587174
25 ft. (7.6m) 587175
NS Backbone Buss Cable Extensions –
2 ft. (0.6 m) 587177
4 ft. (1.5 m) 587178
10 ft. (3.0 m) 587179
15 ft. (4.5 m) 587180
20 ft. (6.0 m) 587181
25 ft. (7.6 m) 587182
22 Network Power Cable, 15 ft. (4.5 m) 587184 10 Amp fuse
22 Network Power Cable, 25 ft. (7.6 m) 587183 10 Amp fuse
NS Network Power Cable Extension, 5 ft. (1.5 m) 587185
NS Network Power Cable Extension, 10 ft. (3.0 m) 587186
23 Fuel Tank Sender –
24 6–Port Hub 587172
25 Connection to NMEA 2000 Accessories – GPS, Triducer, etc.
26 Battery Cable, 10 ft. (3.0 m) 587205
26 Battery Cable, 15 ft. (4.5 m) 587301
26 Battery Cable, 20 ft. (6.0 m) 587302
27 NMEA 2000 Network to Engines 3 & 4 –
28 Remote Control Network to Engines 3 & 4 –
* "Y" Harness (Optional accessory) 587230
Use to power digital displays & accessories to be
powered when the key switch is ON.
