Loading the Configuration Commands from the Network
To use a network server to store large configurations, complete the tasks in this section:
SUMMARY STEPS
1. enable
2. copy system:running-config {ftp: | rcp: | tftp:}
3. configure terminal
4. boot network {ftp:[[[//[username [:password ]@]location ]/directory ]/filename ] |
rcp:[[[//[username@]location ]/directory ]/filename ] | tftp:[[[//location ]/directory ]/filename ]}
5. service config
6. end
7. copy system:running-config nvram:startup-config
DETAILED STEPS
PurposeCommand or Action
Enables privileged EXEC mode.enable
Step 1
Example:
• Enter your password if prompted.
Device> enable
Saves the running configuration to an FTP, RCP, or TFTP
server.
copy system:running-config {ftp: | rcp: | tftp:}
Example:
Step 2
Device# copy system:running-config ftp:
Enters global configuration mode.configure terminal
Example:
Step 3
Device# configure terminal
Specifies that the startup configuration file be loaded from
the network server at startup.
boot network {ftp:[[[//[username [:password ]@]location
]/directory ]/filename ] | rcp:[[[//[username@]location
]/directory ]/filename ] | tftp:[[[//location ]/directory
]/filename ]}
Step 4
Example:
Device(config)# boot network
ftp://user1:guessme@example.com/dir10/file1
Enables the switch to download configuration files at system
startup.
service config
Example:
Step 5
Device(config)# service config
Exits global configuration mode.end
Example:
Step 6
System Management Configuration Guide, Cisco IOS XE Gibraltar 16.10.x (Catalyst 9200 Switches)
166
Managing Configuration Files
Loading the Configuration Commands from the Network

Cisco Catalyst 9200 Specifications

General

Operating System	Cisco IOS XE
Model	Catalyst 9200
Ports	24 or 48
Port Types	10/100/1000BASE-T, 1G/2.5G/5G/10GBASE-T, SFP, SFP+
Switching Capacity	176 Gbps
Forwarding Rate	131 Mpps
Stacking	Yes, up to 8 switches
Security Features	TrustSec
Management	Cisco DNA Center
Operating Temperature	32°F to 104°F (0°C to 40°C)
