Administration: Discovery
Configuring CDP
147 Cisco 500 Series Stackable Managed Switch Administration Guide Release 1.3
9
• Syslog Voice VLAN Mismatch—Select to enable the option of sending a
SYSLOG message when a voice VLAN mismatch is detected This means
that the voice VLAN information in the incoming frame does not match what
the local device is advertising.
• Syslog Native VLAN Mismatch—Select to enable the option of sending a
SYSLOG message when a native VLAN mismatch is detected. This means
that the native VLAN information in the incoming frame does not match what
the local device is advertising.
• Syslog Duplex Mismatch—Select to enable the option of sending a
SYSLOG message when duplex information mismatch is detected. This
means that the duplex information in the incoming frame does not match
what the local device is advertising.
STEP 3 Enter the relevant information, and click Apply. The port settings are written to the
Running Configuration.
Displaying CDP Local Information
To view information that is advertised by the CDP protocol about the local device:
STEP 1 Click Administration > Discovery - CDP > CDP Local Information.
STEP 2 Select a local port, and the following fields are displayed:
• Interface—Number of the local port.
• CDP State—Displays whether CDP is enabled or not.
• Device ID TLV
- Device ID Type—Type of the device ID advertised in the device ID TLV.
- Device ID—Device ID advertised in the device ID TLV.
• System Name TLV
- System Name—System name of the device.
• Address TLV
- Address1-3—IP addresses (advertised in the device address TLV).
• Port TLV
