InteliLite4 AMF20 Global Guide
151
Other functions
Consistency check
Use this function to check if all inputs and outputs of PLC block are connected.
Delete whole content of sheet
Use this function to delete the whole content of sheet (including blocks, wires, inputs, outputs, etc...).
Hints
Use this function to enable or disable quick hints for blocks (controller help is not affected by this function).
PLC monitor
PLC Monitor is a powerful tool for monitoring your PLC. Just click on PLC Monitor button on main InteliConfig
page to see your PLC. Active inputs and outputs are a blue color. Also wires with active signals are blue color.
IMPORTANT: It is not possible to edit PLC in PLC Monitor tool.
5.5.20 Geo-fencing
Geo-fencing function (available with CM2-4G-GPS) is kind of protection that evaluates whether the actual
GPS location is within a predefined area, then based on this evaluation takes an action (sends SMS
message, stops engine, make history record etc.). This function is enabled by setpoint Geo-Fencing (page
324) or by logical binary input GEO-FENCING ENABLE (PAGE 451).
Using InteliConfig, it is possible to set two concentric geo-circles within which the unit is allowed to be located.
Each geo-circle is defined as a circular geographic area with its center (common for both geo-circles) named
Home Position. This point is adjusted via setpoints Home Latitude (page 324) and Home Longitude (page
325) and radius named Fence Radius adjusted via setpoints Fence 1 Radius (page 327) and Fence 2
Radius (page 329).
The Protection can be different for both circles and are adjusted via setpoints Fence 1 Protection (page
326) and Fence 2 Protection (page 328).
It is also possible to see the current position of the controller in WebSupervisor map view.
5.5.21 After-treatment Support
Afer-treatment support generally provides monitoring and control of the after-treatment system installed on
generators engine. The requirements are defined as:
Providing After-Treatment status information by
Displaying universal lamps (icons)
Displaying analog and binary values
Control of After-Treatment regeneration function by
Transmitting commands to the ECU
Providing After-treatment status information
After-Treatment screen
This screen is shown with configured ECU which supports Tier 4 Final / Stage V. The After-Treatment screen
is automatically shown, once any of the selected lamps gets active or change status. Deactivation of the lamp
