InteliLite4 AMF20 Global Guide
240
Subgroup: Stopping Timers
Cooling Time
Setpoint group Engine settings Related FW 1.3.0
Range [units] 0 .. 3 600 [s]
Default value 30 s Alternative config NO
Step 1 s
Comm object 8258 Related applications AMF,MRS
Config level Standard
Setpoint visibility Always
Description
Runtime of the unloaded gen-set to cool the engine before stop.
6 back to List of setpoints
Stop Time
Setpoint group Engine settings Related FW 1.3.0
Range [units] 0 .. 600 [s]
Default value 60 s Alternative config NO
Step 1 s
Comm object 9815 Related applications AMF,MRS
Config level Advanced
Setpoint visibility Always
Description
Under normal conditions the engine must certainly stop within this period after the FUEL SOLENOID (PAGE
477) has been de-energized and the STOP SOLENOID (PAGE 502) energized. The Stop Solenoid output is
deactivated 12 s after last running engine indication went off.
Image 8.7 Stop Time 1
