InteliLite4 AMF20 Global Guide
17
2.6.2 Inteli AIN8
The unit offers the user the flexibility to configure the unit to have 8 analog inputs.
Supported sensors:
Resistor 3-wire input
Common resistor: 0-250Ω, 0-2400Ω, 0-
10kΩ
Temperature sensor: Pt100, Pt1000,
Ni100, Ni1000
Current (active or passive sensors)
±20mA, 0-20mA, 4-20mA
Voltage
±1V, 0-2.4V, 0-5V, 0-10V
Lambda probes
Thermocouples are not supported (the
measuring loop was designed for lambda
probes, which caused non-support of
thermocouples)
Impulse/RPM sensor:
RPM measuring pulses with frequency 4Hz-
10kHz
Impulse
Possibility to measure pulses from
electrometer, flowmeter (measurement of
total consumption, average fuel
consumption)
2.6.3 Inteli AIN8TC
8 Analog Channels Module. The unit offers flexibility to configure 8 thermocouple inputs.
8 analog input channels for measuring
temperature by thermocouples
