InteliLite4 AMF20 Global Guide
18
2.6.4 Inteli AIO9/1
9 Analog Inputs and 1 Analog Output Module
4× differential voltage inputs for measurement
in range of 0 – 65V or -65– 0V
4× shielded, galvanically separated ±75 mV
inputs
Resistance analog input 0-2500Ω
One analog output
2.6.5 IGS-PTM
The unit offers the user the flexibility to configure the unit to have 8 binary inputs, 8 binary outputs, 4 analog
inputs and 1 analog outputs.
Configurable 8 binary and 4 analog inputs
Configurable 8 binary and 1 analog output
LEDs indicate the state of binary inputs/outputs
Measures values from Pt100 and Ni100
sensors
Analog inputs (resistance range 0-250Ω,
voltage range 0-100mV, current range 0-20mA
– selectable via jumper)
UL certified
