4 Installation and wiring
4.1 Package content 22
4.2 Controller installation 22
4.3 Terminal Diagram 24
4.4 Recommended wiring 25
4.5 Plug-in module installation 58
4.6 Maintenance 59
6 back to Table of contents
4.1 Package content
The package contains:
Controller
Mounting holders
Terminal blocks
Note: The package does not contain any communication or extension modules. The required modules
should be ordered separately.
4.2 Controller installation
4.2.1 Dimensions
① Plug-in module
Note: Dimension x depends on plug-in module

ComAp InteliLite 4 AMF 20 Specifications

General

Brand	ComAp
Model	InteliLite 4 AMF 20
Category	Controller
Language	English
