General procedure of non-mission DPF regeneration
This is procedure from user standpoint, and its general idea of non-mission regeneration. There might be
variations depends on specific engine manufacturer.
Regeneration start:
State: lamps signals DPF regeneration is needed
User action: open GCB, prepare Gen-set for regeneration (go to manual mode, turn on LBI GCB Disable,
LBI Force Protections Override, set Overspeed Limit SP)
CU action: turn off protections and change limit for overspeed
User action: close interlock (if interlock is available)
State: Regeneration conditions achieved
User action: activate force regeneration
Regeneration end:
State: lamps stop indicating, regeneration ended (engine now runs in Idle or Nominal speed)
User action: turn of force regeneration (if its not pulse)
User action: interlock open (if its available)
User action: Turn off LBI GCB Disable, LBI Force Protection Override, SP Speed Override Limit
User action: stop engine
Then user can do what he wants.
5.5.22 Alternate configuration
There are 3 sets of alternate configurations in a controller:
Configuration set 1 Configuration set 2 Configuration set 3
Nominal Power Split Phase 1
(page 377)
Nominal Power 1 (page 376)
Nominal RPM 1 (page 372)
Nominal Frequency 1 (page 373)
Nominal Voltage Ph-N 1 (page
373)
Nominal Voltage Ph-Ph 1 (page
373)
Nominal Current 1 (page 374)
Connection Type 1 (page 374)
ECU Speed Adjustment 1 (page
376)
Nominal Power Split Phase 2
(page 382)
Nominal Power 2 (page 381)
Nominal RPM 2 (page 377)
Nominal Frequency 2 (page 378)
Nominal Voltage Ph-N 2 (page
378)
Nominal Voltage Ph-Ph 2 (page
378)
Nominal Current 2 (page 379)
Connection type 2 (page 379)
ECU Speed Adjustment 2 (page
381)
Nominal Power Split Phase 3
(page 387)
Nominal Power 3 (page 386)
Nominal RPM 3 (page 382)
Nominal Frequency 3 (page 383)
Nominal Voltage Ph-N 3 (page
383)
Nominal Voltage Ph-Ph 3 (page
383)
Nominal Current 3 (page 384)
Connection type 3 (page 384)
ECU Speed Adjustment 3 (page
386)
Configuration sets can be changed via logical binary inputs ALTERNATE CONFIG 2 (PAGE 439) and ALTERNATE
CONFIG 3 (PAGE 439). Configuration set 1 is active when there is no input activated. In the case that the inputs
ALTERNATE CONFIG 2 (PAGE 439) and ALTERNATE CONFIG 3 (PAGE 439) are active at the same time,
configuration set 3 is taken in account.
