Programming Manual 60
Field Description
CS0 This field indicates that the data pertains to channel 0 (the primary channel)
PXXX-Y.YYY This data field provides the firmware version of the SBX beacon receiver
SN This item shows the serial number of the SBX
fff.f This field is the current primary channel frequency in kHz (283.5 to 325)
M This field indicates the frequency selection mode (M for manual or A for auto)
ddd This field shows the MSK bit rate
R This field indicates the MSK bit rate selection mode (M for manual or A for auto)
SS This field provides the signal strength reading in dBµV
SNR This field shows the signal to noise ratio in dB
MTP This field indicates the message throughput, measured in percentage
Q This field provides an indication of the word throughput, up to a maximum of 25
successively received good words
ID This data field indicates the currently locked beacon’s station ID
T This field indicates the update period of this message in seconds
An example of this message response follows:
$PCSI,CS0,P021-0.001,19001,287.5,A,200,A,12,2,0,0,943,3,0
7.5 Status Line B, Channel 1 ($PCSI,2)
This query commands the SBX to output a selection of parameters related
to the operational status of its secondary channel. It has the following
format:
$PCSI,2<CR><LF>
The internal SBX will reply with the following response:
$PCSI,ACK,2
$PCSI,CS1,PXXX-Y.YYY,SN,fff.f,M,ddd,R,SS,SNR,MTP,Q,ID,H,T
The SBX will return the above response message when queried for its full
channel status.
Field Description
CS1 This field indicates that the data pertains to channel 1
PXXX-Y.YYY This data field provides the firmware version of the SBX beacon receiver
