D-Link DIR-815/AC User Manual

DIR-815/AC Wireless AC1200 Dual Band Router
with 3G/LTE Support and USB Port
User Manual
Configuring via Web-based Interface
LAN
To configure the router's local interface, go to the Connections Setup / LAN page.
IPv4
Go to the IPv4 tab to change IPv4 address, configure the built-in DHCP server, or specify MAC
address and IP address pairs.
Figure 88. Configuring the local interface. The IPv4 tab. The IP section.
Parameter Description
IP
IP Address
The IP address of the router in the local subnet. By default, the
following value is specified: 192.168.0.1.
Netmask
The mask of the local subnet. By default, the following value is
specified: 255.255.255.0.
Device domain name The name of the device attached to its IP address in the local subnet.
Figure 89. Configuring the local interface. The IPv4 tab. The DHCP section.
Page 108 of 221
