DIR-815/AC Wireless AC1200 Dual Band Router
with 3G/LTE Support and USB Port
User Manual
Configuring via Web-based Interface
Remote Access
On the Advanced / Remote access page, you can configure access to the web-based interface
of the router. By default, the access from external networks to the router is closed. If you need to
allow access to the router from the external network, create relevant rules.
Figure 141. The Advanced / Remote access page.
To create a new rule, click the ADD button.
Figure 142. The window for adding a rule for remote management.
In the opened window, you can specify the following parameters:
Parameter Description
IP version
An IP version to which the rule will be applied. Select the relevant
value from the drop-down list.
Open access from any
external host
Move the switch to the right to allow access to the router for any
host. Upon that the IP address and Mask fields are not displayed.
Page 175 of 221
