DIR-815/AC Wireless AC1200 Dual Band Router
with 3G/LTE Support and USB Port
User Manual
Configuring via Web-based Interface
Port Settings
On the Advanced / Port Settings page, you can configure or disable autonegotiation of speed
and duplex mode or manually configure speed and duplex mode for each Ethernet port of the router.
Also you can enable or disable data flow control in the autonegotiation mode. This function is used
for equal load balancing in ISPs' networks. Contact your ISP to clarify if this function needs to be
enabled.
Figure 131. The Advanced / Port Settings page.
By default, autonegotiation of speed, duplex mode, and data flow control is configured for each
Ethernet port of the router. If you need to specify speed and duplex mode manually or change
autonegotiation settings (speed, duplex mode, or enable/disable data flow control) for a port, select
the relevant port in the table.
!
Autonegotiation should be enabled for both devices connected to each other.
!
When autonegotiation is disabled, speed and duplex mode settings for both devices
connected to each other should be the same.
Page 164 of 221
