51D-Link DSL-124 Wireless N300 ADSL2+ Modem Router User Manual
Section 4 - Conguration
Wireless Basics
This page allows you to manually configure the router’s wireless connectivity settings. To
change your wireless network security settings refer to Wireless Security on page 52.
Disable Wireless
LAN Interface:
Check this box to disable the Wireless functionality of this device.
Band: Select the wireless standards to use on your wireless network. The
options are 2.4 GHz (B), 2.4 GHz (G), 2.4 GHz (B+G), 2.4 GHz (N),
2.4 GHz (N+G), or 2.4 GHz (N+G+B).
Mode: The DSL-124 operates in AP mode by default.
SSID: Enter a unique Network Name (SSID) to identify your network.
Channel Number: Select the channel number for your wireless network to operate
on. Choose 1-13, or Auto. The default is Auto.
Radio Power
(Percent):
Choose the wireless transmission power strength. The options are
100%, 60%, or 20%. The default is 100%.
Associated
Clients:
Click this button to see a list of the currently connected wireless
clients.
Channel Width: Choose the transmission channel bandwidth. The options are 20
MHz or 20/40 MHz.
Control Sideband: Configure Upper or Lower sideband use for 40 MHz connections.
WIRELESS NETWORK SETTINGS
Click Apply Changes to have your changes take effect.
