D-Link DSL-124 User Manual

66D-Link DSL-124 Wireless N300 ADSL2+ Modem Router User Manual
Section 4 - Conguration
Access Control List IPv6
This page allows you to enable or disable various services from being used on the LAN or
WAN side using IPv6 parameters.
Direction Select: Choose either LAN or WAN.
ACLV6 CONFIGURATION  DIRECTION
LAN ACL Switch: Choose either Enable or Disable.
LAN ACL SWITCH CONFIGURATION
IP Address: Enter the IPv6 IP address and prefix.
Services Allowed: Un-check Any to individually select the services which will be
available on your LAN.
ACLV6 SETTINGS
The following settings are available if Direction Select is set to LAN:
Click Add to add the ACLv6 rule.

D-Link DSL-124 Specifications

General

Brand	D-Link
Model	DSL-124
Category	Network Router
Language	English
