D-Link ShareCenter Pulse DNS-320 User Manual

106D-Link ShareCenter Pulse DNS-320 User Manual
Section 5 - Knowledge Base
Yahoo! Widget Installation
®
-Link provides an added feature called a Yahoo! Widget.
What is a Yahoo Widget?
Yahoo! Widgets are free application platforms that can be used in Microsoft Windows and Mac OS X. The engine uses a JavaScript runtime environment
combined with an XML interpreter to run small applications referred to as widgets, and hence is part of a class of software applications called widget
engines.
¯
tep 1:
Step 2:
°
nstall the Yahoo! Widget. Once the Yahoo! Widget is
installed a D-Link icon will appear in your Widget Dock.
Once you hover with your mouse over the D-Link Widget
you’ll be able to click the conguration button.
Click the conguration button to congure the Widget.
Enter the IP Address of your device and click the Save
button. Now you are ready to use your new D-Link Yahoo!
Widget!

D-Link ShareCenter Pulse DNS-320 Specifications

Power

power supply	External Power Supply
power consumption (normal mode)	15.7 W
power consumption (sleep mode)	8.2 W

Operating Environment

operating temperature	0˚ to 40˚ C (32˚ to 104˚ F)
storage temperature	-20˚ to 70˚ C (-4˚ to 158˚ F)
operating humidity	5% to 90% (Non-condensing)

Ports & Interfaces

ethernet port	10/100/1000 Gigabit Ethernet Port
usb port	1 USB 2.0 Port
supported hard drive type	3.5” Internal SATA (Maximum HDD Capacity: 2 TB for each drive)

Weight and Dimensions

dimensions	146.4 x 115 x 178.5 mm (5.8 x 4.5 x 7.0 inches)
weight	0.85 kg (1.87 lbs)
