D-Link ShareCenter Pulse DNS-320 User Manual

12D-Link ShareCenter Pulse DNS-320 User Manual
Section 3 - Installation
Network Setup

ou may use either Static IP or DHCP to configure the IP network settings of the
ShareCenter Pulse. If you select Static IP then input the IP network settings. Click Next
to continue.
If you want your ShareCenter Pulse to be part of a Windows Workgroup network, enter
the parameters requested or leave the default settings that appear initially in the window.
The name will be used whenever you map one of the ShareCenter Pulse volumes as a
Network Drive. Click Next to continue.

D-Link ShareCenter Pulse DNS-320 Specifications

Power

power supply	External Power Supply
power consumption (normal mode)	15.7 W
power consumption (sleep mode)	8.2 W

Operating Environment

operating temperature	0˚ to 40˚ C (32˚ to 104˚ F)
storage temperature	-20˚ to 70˚ C (-4˚ to 158˚ F)
operating humidity	5% to 90% (Non-condensing)

Ports & Interfaces

ethernet port	10/100/1000 Gigabit Ethernet Port
usb port	1 USB 2.0 Port
supported hard drive type	3.5” Internal SATA (Maximum HDD Capacity: 2 TB for each drive)

Weight and Dimensions

dimensions	146.4 x 115 x 178.5 mm (5.8 x 4.5 x 7.0 inches)
weight	0.85 kg (1.87 lbs)
