D-Link ShareCenter Pulse DNS-320 User Manual

8D-Link ShareCenter Pulse DNS-320 User Manual
Section 3 - Installation
Install the Hard Drives

his step shows you how to open your ShareCenter Pulse so that you can install one or
two hard drives. Click Next to continue.
Slide either one or two hard drives into the open hard drive bays of your device. Click
Next to continue.

D-Link ShareCenter Pulse DNS-320 Specifications

Power

power supply	External Power Supply
power consumption (normal mode)	15.7 W
power consumption (sleep mode)	8.2 W

Operating Environment

operating temperature	0˚ to 40˚ C (32˚ to 104˚ F)
storage temperature	-20˚ to 70˚ C (-4˚ to 158˚ F)
operating humidity	5% to 90% (Non-condensing)

Ports & Interfaces

ethernet port	10/100/1000 Gigabit Ethernet Port
usb port	1 USB 2.0 Port
supported hard drive type	3.5” Internal SATA (Maximum HDD Capacity: 2 TB for each drive)

Weight and Dimensions

dimensions	146.4 x 115 x 178.5 mm (5.8 x 4.5 x 7.0 inches)
weight	0.85 kg (1.87 lbs)
