Figure 4-3 Live
Table 4-1 Description of function bar
No. Function Description
1 Encode bar Sets stream type and protocol.
2 Live view Displays the real-time monitoring image.
3 Live view function bar Functions and operations in live viewing.
4 Window adjustment bar Adjustment operations in live viewing.
4.2.2 Encode Bar
Figure 4-4 Encode bar
●
Main Stream : It has large bit stream value and image with high resolution, but also requires
large bandwidth. This option can be used for storage and monitoring. For details, see "4.5.2.1
Video".
●
Sub Stream : It has small bit stream value and smooth image, and requires less bandwidth. This
option is normally used to replace main stream when bandwidth is not enough. For details, see
"4.5.2.1 Video".
●
Protocol : You can select the network transmission protocol as needed, and the options are
TCP, UDP and Multicast.
Before selecting Multicast , make sure that you have set the Multicast parameters.
Operation Manual
11
