Specifications SiUS041111
8 Specifications
1.2 Heat Pump
60 Hz, 208 - 230 V
Note: The data are based on the conditions shown in the table below.
Model
Indoor Unit FTXN09KEVJU FTXN12KEVJU
Outdoor Unit
RXN09KEVJU RXN12KEVJU
Cooling Heating Cooling Heating
Capacity
Rated (Min. ~ Max.)
kW 2.64 (1.30 ~ 2.78) 2.93 (1.3 ~ 3.4) 3.52 (1.3 ~ 3.52) 3.96 (1.3 ~ 4.8)
Btu/h 9,000 (4,400 ~ 9,500) 10,000 (4,400 ~ 11,600) 12,000 (4,400 ~ 12,000) 13,500 (4,400 ~ 16,400)
kcal/h 2,270 (1,120 ~ 2,390) 2,520 (1,120 ~ 2,920) 3,030 (1,120 ~ 3,030) 3,410 (1,120 ~ 4,130)
Running Current (Rated) A 4.4 - 4.0 5.0 - 4.5 6.2 - 5.6 6.3 - 5.7
Power Consumption
Rated
(Min. ~ Max.)
W 750 (330 ~ 800) 840 (310 ~ 910) 1,210 (330 ~ 1,210) 1,220 (310 ~ 1,500)
Power Factor % 81.9 - 81.5 80.8 - 81.2 93.8 - 93.9 93.1 - 93.1
EER (Rated) (Min. ~ Max.) Btu/h-W 12.0 (13.33 ~ 11.90) 11.9 (14.19 ~ 12.75) 9.90 (13.33 ~ 9.90) 11.10 (14.19 ~ 10.90)
COP (Rated) (Min. ~ Max.) W/W 3.52 (3.94 ~ 3.48) 3.49 (4.19 ~ 3.74) 2.90 (3.94 ~ 2.90) 3.25 (4.19 ~ 3.20)
Piping
Connections
Liquid inch (mm) 1/4 (6.4) 1/4 (6.4)
Gas inch (mm) 3/8 (9.5) 3/8 (9.5)
Drain inch (mm) 5/8 (16.0) 5/8 (16.0)
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length feet (m) 65.6 (20) 65.6 (20)
Max. Interunit Height Difference feet (m) 49.2 (15) 49.2 (15)
Chargeless feet (m) 32.8 (10) 32.8 (10)
Amount of Additional Charge of
Refrigerant
oz/ft (g/m) 0.22 (20) 0.22 (20)
Indoor Unit FTXN09KEVJU FTXN12KEVJU
Front Panel Color White White
Airflow Rate
H
cfm
(m³/min)
325 (9.2) 342 (9.7) 328 (9.3) 357 (10.1)
M 244 (6.9) 275 (7.8) 254 (7.2) 293 (8.3)
L 162 (4.6) 212 (6.0) 184 (5.2) 226 (6.4)
SL 138 (3.9) 187 (5.3) 152 (4.3) 201 (5.7)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 16 16
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.20 - 0.18 0.20 - 0.18
Power Consumption (Rated) W 40 40
Power Factor % 96.2 - 96.6 96.2 - 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) inch (mm) 11-9/64 × 30-5/16 × 7-51/64 (283 × 770 × 198) 11-9/64 × 30-5/16 × 7-51/64 (283 × 770 × 198)
Packaged Dimensions (H × W × D) inch (mm) 10-17/64 × 33-7/32 × 13-15/32 (261 × 844 × 342) 10-17/64 × 33-7/32 × 13-15/32 (261 × 844 × 342)
Weight Lbs (kg) 16 (7) 16 (7)
Gross Weight Lbs (kg) 24 (11) 24 (11)
Operation
Sound
H / M / L / SL dB(A) 40 / 33 / 26 / 22 40 / 34 / 28 / 25 42 / 34 / 27 / 23 41 / 35 / 29 / 26
Sound Power dB(A) 56 56 58 57
Outdoor Unit RXN09KEVJU RXN12KEVJU
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 1YC23AEXD 1YC23AEXD
Motor Output W 750 750
Refrigerant
Oil
Type FVC50K FVC50K
Charge oz (L) 12.5 (0.375) 12.5 (0.375)
Refrigerant
Type R-410A R-410A
Charge Lbs (kg) 2.20 (1.0) 2.20 (1.0)
Airflow Rate H
cfm
(m³/min)
921 (26.1) 921 (26.1) 921 (26.1) 921 (26.1)
Fan
Type Propeller Propeller
Motor Output W 33 33
Running Current (Rated) A 4.20 - 3.82 4.80 - 4.32 6.00 - 5.42 6.10 - 5.52
Power Consumption (Rated) W 710 800 1,170 1,180
Power Factor % 81.3 - 80.8 80.1 - 80.5 93.8 - 93.9 93.0 - 93.0
Starting Current A 5.0 6.3
Dimensions (H × W × D) inch (mm) 21-21/32 × 25-29/32 × 10-13/16 (550 × 658 × 275) 21-21/32 × 25-29/32 × 10-13/16 (550 × 658 × 275)
Packaged Dimensions (H × W × D) inch (mm) 23-5/16 × 30-23/64 × 13-45/64 (592 × 771 × 348) 23-5/16 × 30-23/64 × 13-45/64 (592 × 771 × 348)
Weight Lbs (kg) 68 (31) 68 (31)
Gross Weight Lbs (kg) 78 (35) 78 (35)
Operation Sound dB(A) 48 48 50 51
Sound Power dB(A) 62 62 64 65
Drawing No. 3D072505 3D072506
