9.7.20 Figure 20 - BWD250xxx
80
510+40
60+0.2
-
10
6
-
22+2
-
29
1
2
110
98+0.2
-
130BD479.10
1 PTFE wire, AWG 16, white
2 PTFE wire, AWG 16, brown
Table 9.35
Illustration 9.103 BWD250xxx
Specifications Design Guide
MG90O202 Danfoss A/S © Rev. 05/2014 All rights reserved. 131
9 9
