9.8 Mechanical Drawings: Accessories
9.8.1 Mounting Brackets: L Profile
L profile mounting brackets are compatible with the brake resistor types:
•
Flat-pack
Part number Compatible brake resistor type L profile drawing reference
175U0009 1x200 W flat-pack
Illustration 9.112
175U0011
1)
1x100 W flat-pack
1x300 W flat-pack
Illustration 9.113
Table 9.41 L Profile Mounting Brackets
1) Order 2x175U011 for 300 W flat-pack brake resistors.
Part number L-profile bracket Screw Locking washer Cap nut
quantity
supplied
size
[mm]
quantity
supplied
size quantity
supplied
size quantity
supplied
size
175U0011 1
See Table 9.44
2 M4x20 2 S4 2 M4
175U0009 1
See Table 9.44
2 M4x20 2 S4 2 M4
Table 9.42 Items Supplied
Specifications
Design Guide
MG90O202 Danfoss A/S © Rev. 05/2014 All rights reserved. 137
9 9
