Danfoss VLT Brake Resistor MCE 101 User Manual

8.3.4
VLT
®
AQUA Drive FC 202, T2
Mains: 200-240 V, T2
FC 202
P
m
R
min
R
br,nom
Flat-pack IP65
R
rec
per item/P
br,cont.
Duty cycle Danfoss part number
T2 [kW] [Ω] [Ω] [Ω/W] % 175Uxxxx
PK25 0.25 380 691.3 430/100 40 1002
PK37 0.37 380 466.7 430/100 27 1002
PK55 0.55 275 313.7 330/100 18 1003
PK55 0.55 275 313.7 310/200 36 0984
PK75 0.75 188 230.0 220/100 13 1004
PK75 0.75 188 230.0 210/200 26 0987
P1K1 1.1 130 152.9 150/100 9 1005
P1K1 1.1 130 152.9 150/200 18 0989
P1K5 1.5 81.0 110.5 100/100 7 1006
P1K5 1.5 81.0 110.5 100/200 14 0991
P2K2 2.2 58.5 74.1 72/200 9 0992
P3K0 3 45.0 53.7 50/200 7 0993
P3K7 3.7 31.5 39.9 35/200 6 0994
P3K7 3.7 31.5 39.9 72/200 11 2x0992
P5K5 5.5 22.5 28.7 40/200 7 2x0996
Table 8.39 Mains: 200-240 V (T2)
8.3.5
VLT
®
AQUA Drive FC 202, T4
Mains: 380-480 V, T4
FC 202
P
m
R
min
R
br,nom
Flat-pack IP65
R
rec
per item/P
br,cont.
Duty cycle
Danfoss part number
T4 [kW] [Ω] [Ω] [Ω/W] % 175Uxxxx
PK75 0.75 620 910.2 830/100 13 1000
P1K1 1.1 546 607.3 620/100 9 1001
P1K1 1.1 546 607.3 620/200 18 0982
P1K5 1.5 382 437.3 430/100 7 1002
P1K5 1.5 382 437.3 430/200 14 0983
P2K2 2.2 260 293.3 310/200 9 0984
P3K0 3 189 212.7 210/200 7 0987
P4K0 4 135 157.3 150/200 5 0989
P4K0 4 135 157.3 300/200 10 2x0985
P5K5 5.5 99.0 113.3 130/200 7 2x0990
P7K5 7.5 72.0 82.4 80/240 6 2x0090
Table 8.40 Mains: 380-480 V (T4)
Selection Guide Design Guide
MG90O202 Danfoss A/S © Rev. 05/2014 All rights reserved. 63
8 8
