Danfoss VLT Brake Resistor MCE 101 User Manual

8.2.9
VLT
®
2800
10% duty cycle, horizontal braking, 200-400 V
VLT 2800 Horizontal braking 10% duty cycle
Frequency converter data
Brake resistor data Installation
R
rec
[Ω]
P
br,cont.
[kW]
Danfoss part number
Cable
cross-
section
[mm
2
]
Thermo
relay
[A]
Mains
type
P
m
[kW]
R
min
[Ω]
R
br,nom
[Ω]
Wire IP54
Screw
terminal
IP21
Screw
terminal
IP65
Bolt
connection
IP20
2803 (200V) 0.37 275 313 300 0.100 175u3006 - - - 1.5 0.6
2805 (200V) 0.55 185 210 200 0.100 175u3011 - - - 1.5 0.7
2807 (200V) 0.75 135 154 145 0.100 175u3016 - - - 1.5 0.8
2811 (200V) 1.1 91 102 100 0.100 175u3021 - - - 1.5 0.9
2815 (200V) 1.5 66 74 70 0.200 175u3026 - - - 1.5 1.6
2822 (200V) 2.2 44 50 48 0.200 175u3031 - - - 1.5 1.9
2840 (200V) 3.7 22 29 27 0.360 175u3326 175u3477 175u3478 - 1.5 3.5
2805 (400V) 0.55 747 839 850 0.100 175u3001 - - - 1.5 0.4
2807 (400V) 0.75 558 613 630 0.100 175u3002 - - - 1.5 0.4
2811 (400V) 1.1 370 409 410 0.100 175u3004 - - - 1.5 0.5
2815 (400V) 1.5 260 294 270 0.200 175u3007 - - - 1.5 0.8
2822 (400V) 2.2 185 198 200 0.200 175u3008 - - - 1.5 0.9
2830 (400V) 3 135 143 145 0.300 175u3300 - - - 1.5 1.3
2840 (400V) 4 99 106 110 0.450 175u3335 175u3450 175u3449 - 1.5 1.9
2855 (400V) 5.5 74 76 80 0.570 175u3336 175u3452 175u3451 - 1.5 2.5
2875 (400V) 7.5 52 55 56 0.680 175u3337 175u3027 175u3028 - 1.5 3.3
2880 (400V) 11 35 37 38 1.130 175u3338 175u3034 175u3035 - 1.5 5.2
2881 (400V) 15 26 27 28 1.400 175u3339 175u3039 175u3040 - 1.5 6.7
2882 (400V) 18.5 21 22 22 1.700 175u3340 175u3047 175u3048 - 1.5 8.3
Table 8.35 200-400 V, Horizontal Braking 10% Duty Cycle
Selection Guide Design Guide
60 Danfoss A/S © Rev. 05/2014 All rights reserved. MG90O202
