9.3 Electrical Data: MCE 101 Product Types 9xx
P/N
Resi-
stance
Continuous
power 100%
load
Pulse
load
power
10%
duty
cycle
1)
Pulse
load
power
40%
duty
cycle
1)
Temp.
switch
2)
3)
Terminal max wire
cross-section
Wire cross-section
4)
Temp. switch Power cables Temp. switch Power cables
[Ω]
[W] [kW] [kW] Type
[mm
2
]
[AWG]
[mm
2
]
[AWG]
[mm
2
]
[AWG]
[mm
2
]
[AWG]
175U3000 1200 100 1.65 0.405 1 - - - - 0.5 20 1.5 16
175U3001 850 100 1.65 0.405 1 - - - - 0.5 20 1.5 16
175U3002 630 100 1.65 0.405 1 - - - - 0.5 20 1.5 16
175U3003 570 100 1.65 0.405 1 - - - - 0.5 20 1.5 16
175U3004 410 100 1.65 0.405 1 - - - - 0.5 20 1.5 16
175U3005 415 200 3.05 0.75 1 - - - - 0.5 20 1.5 16
175U3006 300 100 1.65 0.405 1 - - - - 0.5 20 1.5 16
175U3007 270 200 3.05 0.75 1 - - - - 0.5 20 1.5 16
175U3008 200 200 3.05 0.75 1 - - - - 0.5 20 1.5 16
175U3009 200 360 4.2 1.05 1 4.0 12 16 6 - - - -
175U3010 200 360 4.2 1.05 1 4.0 12 16 6 - - - -
175U3011 200 100 1.65 0.405 1 - - - - 0.5 20 1.5 16
175U3012 145 450 5 1.25 1 4.0 12 16 6 - - - -
175U3013 145 450 5 1.25 1 4.0 12 16 6 - - - -
175U3014 145 280 2.8 0.7 1 4.0 12 16 6 - - - -
175U3015 145 280 2.8 0.7 1 4.0 12 16 6 - - - -
175U3016 145 100 1.65 0.405 1 - - - - 0.5 20 1.5 16
175U3017 110 360 4.2 1.05 1 4.0 12 16 6 - - - -
175U3018 110 360 4.2 1.05 1 4.0 12 16 6 - - - -
175U3019 105 570 6.6 1.65 1 4.0 12 16 6 - - - -
175U3020 105 570 6.6 1.65 1 4.0 12 16 6 - - - -
175U3021 100 100 1.65 0.405 1 - - - - 0.5 20 1.5 16
175U3022 80 450 5 1.25 1 4.0 12 16 6 - - - -
175U3023 80 450 5 1.25 1 4.0 12 16 6 - - - -
175U3024 72 960 10.8 2.6 1 4.0 12 16 6 - - - -
175U3025 72 960 13 3.3 1 4.0 12 16 6 - - - -
175U3026 70 200 3.05 0.75 1 - - - - 0.5 20 1.5 16
175U3027 56 680 9.4 2.2 1 4.0 12 16 6 - - - -
175U3028 56 680 9.4 2.2 1 4.0 12 16 6 - - - -
175U3029 52 1290 17.8 3.8 1 4.0 12 16 6 - - - -
175U3030 52 1290 17.8 3.8 1 4.0 12 16 6 - - - -
175U3031 48 200 3.05 0.75 1 - - - - 0.5 20 1.5 16
175U3032 42 1700 21.1 5.27 1 4.0 12 16 6 - - - -
175U3033 42 1700 21.1 5.27 1 4.0 12 16 6 - - - -
175U3034 38 1130 15.6 3.3 1 4.0 12 16 6 - - - -
175U3035 38 1130 14.5 3.6 1 4.0 12 16 6 - - - -
175U3036 35 200 3.05 0.75 1 - - - - 0.5 20 1.5 16
175U3037 31 1700 21.1 5.27 1 4.0 12 16 6 - - - -
175U3038 31 1700 21.1 5.27 1 4.0 12 16 6 - - - -
175U3039 28 1400 17.5 4.38 1 4.0 12 16 6 - - - -
175U3040 28 1400 17.5 4.38 1 4.0 12 16 6 - - - -
175U3041 27 280 2.8 0.7 1 4.0 12 16 6 - - - -
175U3042 27 280 2.8 0.7 1 4.0 12 16 6 - - - -
175U3043 27 2200 27.3 6.8 1 4.0 12 16 6 - - - -
175U3044 27 2200 27.3 6.8 1 4.0 12 16 6 - - - -
175U3047 22 1700 21.1 5.27 1 4.0 12 16 6 - - - -
175U3048 22 1700 21.1 5.27 1 4.0 12 16 6 - - - -
175U3049 19 2200 27.3 6.8 1 4.0 12 16 6 - - - -
175U3050 19 2200 27.3 6.8 1 4.0 12 16 6 - - - -
175U3051 15.5 3500 43.4 10.8 1 4.0 12 55 1/0 - - - -
175U3052 15.5 3500 43.4 10.8 1 4.0 12 55 1/0 - - - -
175U3053 18 450 6.2 1.45 1 4.0 12 16 6 - - - -
175U3054 18 450 6.2 1.45 1 4.0 12 16 6 - - - -
175U3055 14 2800 35 8.7 1 4.0 12 16 6 - - - -
175U3056 14 2800 35 8.7 1 4.0 12 16 6 - - - -
175U3057 13.5 4200
52.5 14.8
1 4.0 12 55 1/0 - - - -
Specifications Design Guide
MG90O202 Danfoss A/S © Rev. 05/2014 All rights reserved. 67
