9.4 Mechanical Data: MCE 101 Product Types 9xx
P/N
Weight
[kg]
Enclosure
rating
[IP class]
UL Product type Drawing type Drawing reference
175U3000 0.27 54 Y 914CCH145CT 914CCHxxxCT chapter 9.7.7 Figure 7 - 914CCHxxxCT
175U3001 0.27 54 Y 914CCH145CT 914CCHxxxCT chapter 9.7.7 Figure 7 - 914CCHxxxCT
175U3002 0.27 54 Y 914CCH145CT 914CCHxxxCT chapter 9.7.7 Figure 7 - 914CCHxxxCT
175U3003 0.27 54 Y 914CCH145CT 914CCHxxxCT chapter 9.7.7 Figure 7 - 914CCHxxxCT
175U3004 0.27 54 Y 914CCH145CT 914CCHxxxCT chapter 9.7.7 Figure 7 - 914CCHxxxCT
175U3005 0.54 54 Y 914CCH251CT 914CCHxxxCT chapter 9.7.7 Figure 7 - 914CCHxxxCT
175U3006 0.27 54 Y 914CCH145CT 914CCHxxxCT chapter 9.7.7 Figure 7 - 914CCHxxxCT
175U3007 0.54 54 Y 914CCH251CT 914CCHxxxCT chapter 9.7.7 Figure 7 - 914CCHxxxCT
175U3008 0.54 54 Y 914CCH251CT 914CCHxxxCT chapter 9.7.7 Figure 7 - 914CCHxxxCT
175U3009 1.8 21 Y 914CBR-V210DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3010 1.8 65 Y 914CBR-V210BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3011 0.27 54 Y 914CCH145CT 914CCHxxxCT chapter 9.7.7 Figure 7 - 914CCHxxxCT
175U3012 2.4 21 Y 914CBR-V260DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3013 2.4 65 Y 914CBR-V260BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3014 1.3 21 Y 914CBR-V160DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3015 1.3 65 Y 914CBR-V160BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3016 0.27 54 Y 914CCH145CT 914CCHxxxCT chapter 9.7.7 Figure 7 - 914CCHxxxCT
175U3017 1.8 21 Y 914CBR-V210DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3018 1.8 65 Y 914CBR-V210BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3019 3 21 Y 914CBR-V330DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3020 3 65 Y 914CBR-V330BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3021 0.27 54 Y 914CCH145CT 914CCHxxxCT chapter 9.7.7 Figure 7 - 914CCHxxxCT
175U3022 2.4 21 Y 914CBR-V260DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3023 2.4 65 Y 914CBR-V260BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3024 4.6 21 Y 914CBR-V560DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3025 4.6 65 Y 914CBR-V560BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3026 0.54 54 Y 914CCH251CT 914CCHxxxCT chapter 9.7.7 Figure 7 - 914CCHxxxCT
175U3027 3.5 21 Y 914CBR-V400DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3028 3.5 65 Y 914CBR-V400BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3029 6.1 21 Y 914CBR-V760DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3030 6.1 65 Y 914CBR-V760BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3031 0.54 54 Y 914CCH251CT 914CCHxxxCT chapter 9.7.7 Figure 7 - 914CCHxxxCT
175U3032 9.2 21 N 914CBT-H460DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3033 9.2 65 N 914CBT-H460BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3034 5.4 21 Y 914CBR-V660DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3035 5.4 65 Y 914CBR-V660BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3036 0.54 54 Y 914CCH251CT 914CCHxxxCT chapter 9.7.7 Figure 7 - 914CCHxxxCT
175U3037 9.2 21 N 914CBT-H460DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3038 9.2 65 N 914CBT-H460BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3039 8.2 21 N 914CBT-H400DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3040 8.2 65 N 914CBT-H400BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3041 1.3 21 Y 914CBR-V160DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3042 1.3 65 Y 914CBR-V160BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3043 11 21 N 914CBT-H560DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3044 11 65 N 914CBT-H560BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3047 9.2 21 N 914CBT-H460DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3048 9,2 65 N 914CBT-H460BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3049 11 21 N 914CBT-H560DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3050 11 65 N 914CBT-H560BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
Specifications Design Guide
74 Danfoss A/S © Rev. 05/2014 All rights reserved. MG90O202
