Danfoss VLT Brake Resistor MCE 101 User Manual

P/N
Weight
[kg]
Enclosure
rating
[IP class]
UL Product type Drawing type Drawing reference
175U3483 9.2 21 N 914CBT-H460DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3484 9.2 65 N 914CBT-H460BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
Table 9.2 Mechanical Data: Product Types 9xx
9.5 Electrical Data: Product Types BWD and BWG
P/N Resistance Continuous power
Temperature
switch
Wire cross-section
Fixed cable
see footnotes
100% load Power cables
[W]
[mm
2
]
[AWG]
175U0089 60 200 No 1.5 16
1)
175U0090 80 240 No 2.5 14
1)
175U0091 72 240 No 2.5 14
1)
175U0982 620 200 No 1.5 16
1)
175U0983 430 200 No 1.5 16
1)
175U0984 310 200 No 1.5 16
1)
175U0985 300 200 No 1.5 16
1)
175U0986 240 200 No 1.5 16
1)
175U0987 210 200 No 1.5 16
1)
175U0988 160 200 No 1.5 16
1)
175U0989 150 200 No 1.5 16
1)
175U0990 130 200 No 1.5 16
1)
175U0991 100 200 No 1.5 16
1)
175U0992 72 200 No 1.5 16
1)
175U0993 50 200 No 1.5 16
1)
175U0994 35 200 No 1.5 16
1)
175U0995 27 200 No 1.5 16
1)
175U0996 40 200 No 1.5 16
1)
175U1000 830 100 No 1.5 16
1)
175U1001 620 100 No 1.5 16
1)
175U1002 430 100 No 1.5 16
1)
175U1003 330 100 No 1.5 16
1)
175U1004 220 100 No 1.5 16
1)
175U1005 150 100 No 1.5 16
1)
175U1006 100 100 No 1.5 16
1)
175N2395 430 100 No 1.5 16
2)
175N2396 620 100 No 1.5 16
2)
175N2397 830 100 No 1.5 16
2)
175N2398 150 200 No 1.5 16
2)
175N2399 210 200 No 1.5 16
2)
175N2400 310 200 No 1.5 16
2)
Table 9.3 Electrical Data: Product Types BWD and BWG
1) 510 mm unscreened cables
2) 800 mm Ø8 screened cable
