Plug and Play
Product Reference Guide 1-9
ACK/NAK Mode
Connecting the imager in Universal Key-
board Wedge mode
The Universal Keyboard Wedge (UKBW) model allows an RS-232
transmission or Keyboard Wedge mode according to the type of cable
connected. Contact Datalogic or your dealer for cable and/or power sup-
ply part numbers.
1. Turn off power to the terminal/computer.
2. Connect the keyboard wedge interface cable to the imager.
NOTE
Reference the Product Reference Guide (PRG) for
more information about keyboard support.
NOTE
For the imager to work properly, you must have
the correct cable for your type of terminal/com-
puter.
