Standard Cable Pinouts (Primary Interface Cables)
Product Reference Guide 11-3
Standard Cable Pinouts (Primary
Interface Cables)
Serial Output
10 Pin RJ41 Modular Plug
connects to the imager handle
1
2CTS
3
4RTS
5RXD
6TXD
7
8VCC_IN
9GND
10 Cable Select
