Steps
1 Align the screw holes on the battery with the screw holes on the palm rest and keyboard assembly.
2 Replace the two screws (M2x3) that secure the battery to the palm-rest and keyboard assembly.
3 Connect the battery cable to the system board.
Next steps
1 Install the base cover.
2 Follow the procedure in After working inside your computer.
Identifier GUID-2A6DAE1B-1FBE-40F9-8D46-40E8C3FBD267
Status Released
Memory modules
Identifier GUID-D1F7FD84-7CAA-4775-A9B9-B9859B7196DE
Status Released
Removing the memory module
Prerequisite
1 Follow the procedure in Before working inside your computer.
2 Remove the base cover.
About this task
The following image indicates the location of the memory module and provides a visual representation of the removal procedure.
16
Removing and installing components
