2 Remove the base cover.
3 Remove the battery.
About this task
The following image indicates the location of the coin-cell battery and provides a visual representation of the removal procedure.
Steps
1 Using a plastic scribe, push the coin-cell battery from the right to release it.
2 Gently lift the coin-cell battery out from the system board.
Identifier GUID-1A7CA395-295B-4956-9D1E-CEC6622607D3
Status Released
Installing the coin-cell battery
Prerequisite
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following image indicates the location of the coin-cell battery and provides a visual representation of the installation procedure.
Removing and installing components
19
