Steps
1 Open the latch and disconnect the hard-drive cable from the system board.
2 Remove the three screws (M2x3) that secure the hard-drive assembly to the palm rest and keyboard assembly.
3 Lift the hard-drive assembly along with its cable oî the palm rest and keyboard assembly.
4 Disconnect the interposer from the hard-drive assembly.
5 Remove the four screws (M3x3) that secure the hard-drive bracket to the hard drive.
6 Remove the hard drive from the hard-drive bracket.
Identifier GUID-2949E4A7-8CDC-438B-A9DF-00A520DB167B
Status Released
Installing the hard drive
Prerequisite
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following image indicates the location of the hard drive and provides a visual representation of the installation procedure.
26 Removing and installing components
