4 Install the heat sink.
5 Install the left fan.
6 Install the right fan.
7 Install the WLAN card.
8 Install the solid-state drive/Intel Optane memory module.
9 Install the battery.
10 Install the base cover.
11 Follow the procedure in After working inside your computer.
Identifier GUID-4AAEA62D-3F30-4E6E-ADEC-AD46B79B8EA6
Status Released
Palm-rest and keyboard assembly
Identifier GUID-31169B40-7319-4910-98EC-40F9D3DD0D09
Status Released
Removing the palm-rest and keyboard assembly
Prerequisites
1 Follow the procedure in Before working inside your computer.
2 Remove the base cover.
3 Remove the battery.
4 Remove the memory modules.
5 Remove the WLAN card.
6 Remove the left fan.
7 Remove the right fan.
8 Remove the solid-state drive/Intel Optane memory module.
9 Remove the hard drive.
10 Remove the I/O board.
11 Remove the touchpad.
12 Remove the speakers.
13 Remove the display assembly.
14 Remove the power-adapter port.
15 Remove the system board.
NOTE
: The system board can be removed with the heat sink attached.
About this task
After performing the steps in the pre-requisites, we are left with the palm-rest and keyboard assembly.
52
Removing and installing components
