Delta AS218TX-A User Manual

2.4 Analog Input/Output Module Specifications
2.4.1 General Specifications
 AS04AD-A / AS08AD-B / AS08AD-C
Electrical specifications
Module Name
AS04AD-A
AS08AD-B
AS08AD-C
Number of Inputs
4 8 8
Analog-to-Digital
Conversion
Voltage input/Current input Voltage input Current input
Supply Voltage
24 VDC (20.4 VDC–28.8 VDC) (-15% to +20%)
Connector Type
Removable terminal block
Conversion Time
2 ms / channel; for FW V1.02.00 or later, upgraded to 1 ms/channel
Isolation
An analog circuit is isolated from a digital circuit by a digital integrated circuit/
optocoupler, but the analog channels are not isolated from one another.
Isolation between a digital circuit and a ground: 500 VAC
Isolation between an analog circuit and a ground: 500 VAC
Isolation between an analog circuit and a digital circuit: 500 VAC
Isolation between the 24 VDC and a ground: 500 VAC
Weight
145g
Functional specifications
Analog-to-Digital
Conversion
Voltage Input
Rated Input Range
-10 V ~ +10 V
0 V ~ 10 V
±5 V
0 V ~ 5 V
1 V ~ 5 V
Rated Conversion
Range
K-32000
~
K32000
K0
~
K32000
K-32000
~
K32000
K0
~
K32000
K0
~
K32000
Hardware Input
Limit*
1
-10.12V
~
10.12V
-0.12V
~
10.12V
-5.06V
~
5.06V
-0.06V
~
5.06V
0.95V
~
5.05V
Conversion Limit*
2
K-32384
~
K32384
K-384
~
K32384
K-32384
~
K32384
K-384
~
K32384
K-384
~
K32384
Error Rate
Room Temperature: ±0.2% ; Full Temperature Range: ±0.5%
Hardware
Resolution
16 bits
Input Impedance
2MΩ
Absolute Input
Range*
3
±15 V
*1: If the input signal exceeds the hardware input limit, the module only shows the maximum value. If the
input signal is below the lower limit, it only shows the minimum value. And an error flag will be set.
*2: If the input signal exceeds the hardware input limit, it also exceeds the conversion limit and a
conversion limit error appears. For example in the voltage input mode (-10 V to +10 V), when the input
signal is 10.15 V, exceeding the hardware upper limit, it also exceeds the conversion upper limit. The
module uses the upper limit value (32387) as the input signal and a conversion limit error appears.
*3: If an input signal exceeds the absolute range, it might damage the channel.
