Delta AS218TX-A User Manual

4.13.5 AS04SIL-A
Q 2
Q 4
E 4
Q3
E 3
C 4
E 2
C3
C Q 1
Q 1
E 1
C 2
MS
NS
C 1
P WR
04SIL
●
CQ 2
L3+
L3
-
L4+
L4
-
DI 1
D I2
CQ 3
D I3
CQ 4
D I4
L2+
L2
-
L1+
L1
-
2 4V
0 V
4.13.6 Wiring AS04SIL-A
4.13.6.1 IO-Link mode communication and power wiring
(1) Keep the input cables, output cables, and power cable separate from one another. It is suggested to use
independent power for AS04SIL-A. See the example below.
IO-Link (Master)
AS04SIL-A
CQ1 L1+
DI1 L1-
CQ2 L2+
DI2 L2-
CQ3 L3+
DI3 L3-
CQ4 L4+
DI4 L4-
. 24V
0V
1 Brown
3 Blue
4 Black
1 Brown
3 Blue
4 Black
2 White
IO-Link Sensor
(with DI)
DC Power Supply
24VDC
24V
0V
.
.
.
.
.
.
.
IO-Link Sensor
(without DI)
