Delta C2000 Series User Manual

Chapter 7 Optional AccessoriesC2000
7-2
Table 7-1
The optional accessories listed in this chapter are available upon request. Installing additional
accessories to your drive would substantially improve the drive’s performance. Please select an applicable
accessory according to your need or contact the local distributor for suggestion.
7-1 All Brake Resistors and Brake Units Used in AC Motor Drives
230V
Applicable
Motor
*
1
125% Braking Torque 10% ED *
2
Max. Braking Torque
HP kW
Braking
Torque
[kg-m]
Brake
Unit
*
3
Braking Resistor for each
Brake Unit
Resistor value
spec. for each
AC motor Drive
Total
Braking
Current [A]
Min.
Resistor
Value [Ω]
Max. Total
Braking
Current [A]
Peak
Power
[kW]
*
4
VFDB
1 0.7 0.5 - BR080W200*1 80W 200Ω 1.9 63.3 6 2.3
2 1.5 1.0 - BR200W091*1 200W 91Ω 4.2 47.5 8 3.0
3 2.2 1.5 - BR300W070*1 300W 70Ω 5.4 38.0 10 3.8
5 3.7 2.5 - BR400W040*1 400W 40Ω 9.5 19.0 20 7.6
7.5 5.5 3.7 - BR1K0W020*1 1000W 20Ω 19 14.6 26 9.9
10 7.5 5.1 - BR1K0W020*1 1000W 20Ω 19 14.6 26 9.9
15 11 7.5 - BR1K5W013*1 1500W 13Ω 29 12.6 29 10.6
20 15 10.2 - BR1K0W4P3*2 2 series 2000W 8.6Ω 44 8.3 46 17.5
25 18 12.2 - BR1K0W4P3*2
2 series
2000W 8.6Ω 44 8.3 46 17.5
30 22 14.9 - BR1K5W3P3*2
2 series
3000W 6.6Ω 58 5.8 66 25.1
40 30 20.3 2015*2 BR1K0W5P1*2
2 series
4000W 5.1Ω 75 4.8 80 30.4
50 37 25.1 2022*2 BR1K2W3P9*2
2 series
4800W 3.9Ω 97 3.2 120 45.6
60 45 30.5 2022*2 BR1K5W3P3*2
2 series
6000W 3.3Ω 118 3.2 120 45.6
75 55 37.2 2022*3 BR1K2W3P9*2
2 series
7200W 2.6Ω 145 2.1 180 68.4
100 75 50.8 2022*4 BR1K2W3P9*2
2 series
9600W 2Ω 190 1.6 240 91.2
125 90 60.9 2022*4 BR1K5W3P3*2
2 series
12000W 1.65Ω 230 1.6 240 91.2
460V
Applicable
Motor
*
1
125% Braking Torque 10% ED *
2
Max. Braking Torque
HP kW
Braking
Torque
[kg-m]
Brake
Unit
*
3
Braking Resistor for each
Brake Unit
Resistor value
spec. for each
AC motor Drive
Total
Braking
Current [A]
Min.
Resistor
Value [Ω]
Max. Total
Braking
Current [A]
Peak
Power
[kW]
*
4
VFDB
1 0.7 0.5 - BR080W750*1 80W 750Ω 1 190.0 4 3.0
2 1.5 1.0 - BR200W360*1 200W 360Ω 2.1 126.7 6 4.6
3 2.2 1.5 - BR300W250*1 300W 250Ω 3 108.6 7 5.3
5 3.7 2.5 - BR400W150*1 400W 150Ω 5.1 84.4 9 6.8
5.5 4.0 2.7
- BR1K0W075*1 1000W 75Ω 10.2 54.3 14 10.6
7.5 5.5 3.7
10 7.5 5.1 - BR1K0W075*1 1000W 75Ω 10.2 47.5 16 12.2
15 11 7.5 - BR1K5W043*1 1500W 43Ω 17.6 42.2 18 13.7
20 15 10.2 - BR1K0W016*2 2 series 2000W 32Ω 24 26.2 29 22.0
25 18 12.2 - BR1K0W016*2 2 series 2000W 32Ω 24 23.0 33 25.1
30 22 14.9 - BR1K5W013*2 2 series 3000W 26Ω 29 23.0 33 25.1
40 30 20.3 - BR1K0W016*4
2 parallel,
2 series
4000W 16Ω 47.5 14.1 54 41.0
50 37 25.1 4045*1 BR1K2W015*4
2 parallel,
2 series
4800W 15Ω 50 12.7 60 45.6
60 45 30.5 4045*1 BR1K5W013*4
2 parallel,
2 series
6000W 13Ω 59 12.7 60 45.6
75 55 37.2 4030*2 BR1K0W5P1*4 4 series 8000W 10.2Ω 76 9.5 80 60.8
100 75 50.8 4045*2 BR1K2W015*4
2 parallel,
2 series
9600W 7.5Ω 100 6.3 120 91.2
125 90 60.9 4045*2 BR1K5W013*4
2 parallel,
2 series
12000W 6.5Ω 117 6.3 120 91.2
150 110 74.5 4110*1 BR1K2W015*10
5 parallel,
2 series
12000W 6Ω 126 6.0 126 95.8
175 132 89.4 4160*1 BR1K5W012*12
6 parallel,
2 series
18000W 4Ω 190 4.0 190 144.4
215 160 108.3 4160*1 BR1K5W012*12
6 parallel,
2 series
18000W 4Ω 190 4.0 190 144.4
250 185 125.3 4185*1 BR1K5W012*14
7 parallel,
2 series
21000W 3.4Ω 225 3.4 225 172.1
