Delta C2000 Series User Manual

Chapter 12 Description of Parameter SettingsC2000
12.1-04-4
Multi-step position corresponding MI4 MI3 MI2 MI1 Multi-step speed corresponding
04-22 Position command 4 (pulse) 0 1 0 0 04-03 4
th
step speed frequency
04-24 Position command 5 (pulse) 0 1 0 1 04-04 5
th
step speed frequency
04-26 Position command 6 (pulse) 0 1 1 0 04-05 6
th
step speed frequency
04-28 Position command 7 (pulse) 0 1 1 1 04-06 7
th
step speed frequency
04-30 Position command 8 (pulse) 1 0 0 0 04-07 8
th
step speed frequency
04-32 Position command 9 (pulse) 1 0 0 1 04-08 9
th
step speed frequency
04-34 Position command 10 (pulse) 1 0 1 0 04-09 10
th
step speed frequency
04-36 Position command 11 (pulse) 1 0 1 1 04-10 11
th
step speed frequency
04-38 Position command 12 (pulse) 1 1 0 0 04-11 12
th
step speed frequency
04-40 Position command 13 (pulse) 1 1 0 1 04-12 13
th
step speed frequency
04-42 Position command 14 (pulse) 1 1 1 0 04-13 14
th
step speed frequency
04-44 Position command 15 (pulse) 1 1 1 1 04-14 15
th
step speed frequency

PLC Buffer 0

PLC Buffer 1

PLC Buffer 2

PLC Buffer 3

PLC Buffer 4

PLC Buffer 5

PLC Buffer 6

PLC Buffer 7

PLC Buffer 8

PLC Buffer 9


PLC Buffer 10


PLC Buffer 11


PLC Buffer 12


PLC Buffer 13


PLC Buffer 14


PLC Buffer 15


PLC Buffer 16


PLC Buffer 17


PLC Buffer 18


PLC Buffer 19
Default: 0
Settings 0–65535
 You can combine the PLC buffer with the built-in PLC function for a variety of applications.
