Delta SOLIVIA 10 EU T4 TL User Manual

116
Technical data
10EUT4TL 15EUG4TL 20EUG4TL 30EUT4TL
Grid Interface VDE-AR-N 4105,
CEI 0-21, VDE
0126-1-1
VDE-AR-N 4105, BDEW, VDE
0126-1-1; G59/1-2 (230 V & 240
V); EN 50438; UTE C15-712-1,
Synergrid C10/C11 BT, Synergrid
C10/C11 2012, RD661/2007,
RD1699/2011, CEI 0-21, French
Islands 60 Hz.,
TERNA A70, AS 4777, SONDO
Class C
VDE-AR-N
4105,CEI 0-21,
SONDO Class C
EMC EN61000-6-2;
EN61000-6-3
EN61000-6-2; EN61000-6-3;
EN61000-3-11, EN61000-3-12,
C-Tick
EN61000-6-2;
EN61000-6-3,
EN61000-3-11,
EN61000-3-12
1)
When operated with balanced DC inputs (50/50 %)
2)
The maximum AC apparent power indicates the power an inverter is able to deliver. This maximum apparent power may not
necessarily be reached.
3)
AC voltage and frequency range will be programmed according to the individual country requirements.
4)
IP55 for cooling section / IP65 for electronics
12.2 Cable Recommendations
Power wiring
Current rating Cross-section Recommended max. cable
loss calculation
AC - < 40 A (10 TL / 15 TL /
20 TL) < 60 A (30 TL)
Calculated based on needed
length, used material, cable
losses and etc.
<1 %
DC 34 A 6 mm
2
<1 %
Communication cable
RS485 modular communication cable / cross wired 8 poles
