SPECIFICATIONS
2 Audio section
• Power amplifier
Output power (6 Ω/ohms, 1 kHz, 10% THD, 100W)
- TStereo ..........................................2 x 100 W
Output power (6 Ω/ohms, 1 kHz, 10% THD, 100W)
- Front left/right ................................2 x 100 W
- Center ............................................100 W
- Surround left/right ..........................2 x 100 W
- Subwoofer ......................................100 W
Signal-to-Noise Ratio
- Stereo-TV........................................> 67 dB (IHF-A)
- Surround front/center/rear ..............> 65 dB (IHF-A, –20 dB FS)
Frequency Response ..............................10 Hz - 20 kHz, –3 dB/+1 dB
Input Sensitivity ......................................300 mV / 47 kΩ/kohms
Cross-talk (separation)
- Stereo-TV (line) ..............................> 55 dB
- Dolby Digital ..................................> 45 dB
2 Tuner section
Tuning Range ..........................................FM 87.5 ~ 108 MHz (50 kHz steps)
AM 522 ~ 1611 kHz (9 kHz steps)
26 dB Quieting Sensitivity ......................FM < 22 dBf
AM < 3250 /m
Harmonic Distortion (15 kHz LPF on) ......FM Mono < 3%
FM Stereo < 2%
Signal-to-Noise Ratio................................FM Mono > 60 dB
FM Stereo > 60 dB
AM > 40 dB
Frequency Response ..............................FM 20 Hz - 15 kHz, –3 dB
Selectivity ................................................AM > 25 dB
2 Video section
• Standard video jacks
Input / output level and impedance: ........1 Vp-p, 75 Ω/ohms
• S-video jacks
Input / output level and impedance: ........Y (brightness) signal 1 Vp-p, 75 Ω/ohms
C (color) signal 0.3 Vp-p, 75 Ω/ohms
• AV connector ................................................Video output 1 Vp-p, 75 Ω/ohms
RGB output (DVD only) R/G/B signal — 0.7 Vp-p, 75 Ω/ohms
Audio output L/R (Fixed output)
2 DVD section
Signal system ..........................................NTSC/PAL
Applicable discs ......................................(1) DVD-Video discs
1-layer 12 cm single-sided discs, 2-layer 12 cm single-sided
discs, 2-layer 12 cm double-sided discs (1 layer per side)
1-layer 8 cm single-sided discs, 2-layer 8 cm single-sided
discs, 2-layer 8 cm double-sided discs (1 layer per side)
(2)Compact discs (CD-DA, Video CD)
12 cm discs, 8 cm discs
Audio output ............................................Fixed output level: 2 Vrms, (VIDEO1 OUT, TV)
(1) DVD Surround Receiver (ADV-500SD)
2 Satellite (Front/Rear) speaker system (SC-A500SD)
Type..........................................................2-way, 3-speakers
Closed box / Low-leakage-flux
Speakers ..................................................5.7 cm cone bass-mid x 2
1.9 cm super-high range x 1
Input impedance ......................................6 Ω/ohms
Max. input ................................................40 watts (IEC) 100 watts (PEAK)
Frequency range ......................................120 Hz ~ 90 kHz
Dimensions ..............................................70 (W) x 210 (H) x 155 (D) mm
Mass ........................................................1.1 kg (one unit)
2 Center speaker system (SC-C500SD)
Type..........................................................2-way, 3-speakers
Closed box / Low-leakage-flux
Speakers ..................................................5.7 cm cone bass-mid x 2
1.9 cm super-high range x 1
Input impedance ......................................6 Ω/ohms
Max. input ................................................40 watts (IEC) 100 watts (PEAK)
Frequency range ......................................120 Hz ~ 90 kHz
Dimensions ..............................................210 (W) x 72 (H) x 155 (D) mm
Mass ........................................................1.1 kg (one unit)
2 Passive subwoofer (DSW-500SD)
Type..........................................................1-way, 1-speaker
Reflex box / Low-leakage-flux
Speaker ....................................................16 cm cone woofer x 1
Input impedance ......................................6 Ω/ohms
Max. input ................................................50 watts (IEC) 100 watts (PEAK)
Frequency range ......................................29 Hz ~ 240 Hz
Dimensions ..............................................210 (W) x 316 (H) x 352 (D) mm
Mass ........................................................5.8 kg (one unit)
(2) Speaker System (SYS-500SD)
✽ Design and specifications are subject to change without notice in the course of product improvement.
This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other
intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection
technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only
unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
2 General
Power supply ..........................................AC 230 V, 50 Hz
Power consumption ................................155 W (Standby 1 W)
Maximum external dimensions ..............434 (width) x 80 (height) x 368 (depth) mm
Mass ........................................................5.4 kg
2 Remote control unit RC-973
Type..........................................................Infrared pulse
Power supply ..........................................DC 3 V, 2 “R6P/AA” batteries
