LABEL EDITOR DEFAULT SETUP
Element Property Defaults
To set the default property values for text and image elements that are used in the label creator:
1.
Select Home > Setup > Editor defaults > Element property defaults.
2.
Define the default settings for text and image elements.
End of procedure.
Content Property Defaults
To set the default content property values for clocks, counters, reference, script and variable
elements that are used in the label creator:
1.
Select Home > Setup > Editor defaults > Content property defaults.
2. Define the default settings for the clock, counter, reference, script, and variable text
elements.
End of procedure.
Label Defaults
To set the default label settings that are used in the label creator:
1. Select Home > Setup > Global print settings > Label defaults.
2. The settings listed below can now be defined:
Setting Name Explanation
Label width (mm) Define the print width of the label in millimetres.
Forward oset (mm) Define a space before the start of the label to position the label on
the print surface.
Reversed oset (mm) Define a space after the end of the label to position the label on
the print surface.
Box width (mm)
Note This setting is used when a single photocell encoder
is used to measure the production line speed.
Set the size of products on the production line.
Delay after Input Intell.
Microp. (mm)
Set a delay before the intelligent micro purge.
Speed modification (%) Shrink or stretch printing when external print speed mode is
selected (negative values shrink, positive values stretch).
Production speed (m/min) Set the fixed print speed when Print speed mode is set to Internal.
Or, set the speed for the first label, if a photocell encoder is used
to measure the production line speed.
INSTALLATION
101 EPT053091 - Issue 5 - 07 May 2021
