QUICKSTEP INTERFACE
Home Screen
When starting the printer, the Home screen below is displayed.
# Setting Name Explanation
A Information Bar Displays printer information.
B Start Start printing.
C Stop Stop printing.
D Status Tab Displays printer status and alerts. If more than one alert is
present, the highest priority alert is displayed.
If an alert is displayed, select the Status Tab to show more
information and to clear the alert.
E Assign Label
(Print Group 1)
Select and assign a label to print group 1.
F Assign Label
(Print Group 2)
Select and assign a label to print group 2.
G Assign Label
(Print Group 3)
Select and assign a label to print group 3.
OPERATION
115 EPT053091 - Issue 5 - 07 May 2021
