Outputs
To assign functions to I/O outputs:
1.
Select Home > Setup > Production line setup > I/O.
2.
Scroll down to the outputs.
3.
Select an output and assign a function:
Item Details
Unassigned No function.
Alarm The output will be triggered when the print group is in an alarm
(red) state.
Warning The output will be triggered when the print group is in a warning
(amber) state.
Counter End The output will be triggered when a counter in the label reaches its
end value.
Ink Cartridge Empty The output will be triggered an ink cartridge is empty.
Ready to Print The output will be triggered when the print group is in the ready to
print state.
Printing Active The output will be triggered when the print group is printing.
Trigger Output This output is intended to trigger external equipment after a print
trigger signal is received. More trigger output settings can be
defined in the Print trigger menu, see Print Trigger Setup on page
79.
This output can also be linked to an input on the Gx-Series
controller.
Print Image Ready The output will be triggered when the Gx-Series is ready to print.
Print Done The output will be triggered when a print has been made.
Controller Online The output will be triggered when the controller is powered on, the
user is able to directly operate the controller, or operate the
controller using the communication protocols.
EDC buer empty The output will be triggered when the external data buer
becomes empty.
Promotional Coding failed
to send data
The output will be triggered when the controller failed to receive
promotional coding data.
EDC failed to send data The output will be triggered when the controller failed to receive
EDC data.
4.
The settings described below can also be setup:
Item Details
Target position Specify which print groups the output will be triggered by.
Active level Specify if an active output is a high or low signal.
INSTALLATION
EPT053091 - Issue 5 - 07 May 2021 84
